• Extremely fast! Programs and verifies programming of 1Gb NAND flash memory device for 23 s! Targeted at working with large density NAND and NOR flash memory devices. See the speed comparison between different programmers.
  • Supports parallel and serial Flash memory devices, EPROM, EEPROM, microcontrollers with embedded Flash and OTP memory and PAL/PALCE/GAL/PEEL/PLD devices
  • Programs all DIP-packed device from 6 to 48 pin via a 48-pin pin ZIF DIP socket - no additional adapters are required
  • Optional adapters for programming devices in PLCC, SOIC, SSOP, QFP, BGA, QFN, SON and other packages are available
  • Supports in-system programming for the devices allowing the ISP (ICP) mode via special cables-adapters
  • Communicates to a PC via a high speed USB 2.0 port
  • Being based on a fast 32-bit microcontroller and a FPGAs, provides very fast loading & programming
  • Works under control of Windows XP and Windows 7 32- and 64-bit versions. Easy-to-use and intuitive user interface
  • Allows to work in a multi-programmer mode - unlimited number of ChipProg units can be driven from one computer
  • 'Start' button for fast manual operations programmable to execute a single operation or a batch of them
  • Supports loading files of all popular formats: Intel HEX, Binary, Motorola S-format, POF, JEDEC, PRG, ASCII Hex & Octal, etc.
  • Built-in editor supports sophisticated operations with blocks
  • Vpp and other parameters precise adjustment via the software settings
  • Splits files to multiple images
  • Embedded script language for automation of routine operations
  • Serialization of the programmed devices by writing a serial number into a specified target memory location
  • Calculation of the control sum with capability to write it into a specified target memory location
  • A unique signature can be written into a specified target memory location
  • Advanced self-diagnostic start-up routine that check the target device reliable contact in the programming socket
  • Incorrect device insertion check and overcurrent protection; automatically detects bad contacts before starting any operation
  • Lifetime free software updates via Web
  • Very small – 160x90x25 mm (6¼x3¾x1 inch)
